Upgrade IOS Cisco 3850 from 3.x.x to 16.x.x

Below are the steps to upgrade IOS from 3.x.x to 16.x.x
The key to the install is this command:
software install file flash:cat3k_caa-universalk9.16.03.05b.SPA.bin verbose new force

The keyword is verbose, new and force.

Output below:

scg-keswick-ds-switch#show usbflash0:

%Error show usbflash0: (No such device)

*Jul 29 18:42:27.349: %IOSD_INFRA-5-IFS_DEVICE_OIR: Device usbflash0 added

scg-keswick-ds-switch#show usbflash0:

-#- --length-- ---------date/time--------- path

2 4096 Jul 30 2018 10:47:12.0000000000 +00:00 System Volume Information

3 12 Jul 30 2018 10:47:12.0000000000 +00:00 System Volume Information/WPSettings.dat

4 76 Jul 30 2018 10:47:16.0000000000 +00:00 System Volume Information/IndexerVolumeGuid

5 305292424 Jul 30 2018 10:41:12.0000000000 +00:00 cat3k_caa-universalk9.SPA.03.06.08.E.152-2.E8.bin

6 539622403 Jul 27 2018 13:37:08.0000000000 +00:00 cat3k_caa-universalk9.16.03.05b.SPA.bin

7141085184 bytes available (844935168 bytes used)

scg-keswick-ds-switch#

scg-keswick-ds-switch#software clean

Preparing clean operation ...

[1]: Cleaning up unnecessary package files

[1]: No path specified, will use booted path flash:packages.conf

[1]: Cleaning flash:

[1]: Preparing packages list to delete ...

In use files, will not delete:

cat3k_caa-base.SPA.03.06.08E.pkg

cat3k_caa-drivers.SPA.03.06.08E.pkg

cat3k_caa-infra.SPA.03.06.08E.pkg

cat3k_caa-iosd-universalk9.SPA.152-2.E8.pkg

cat3k_caa-platform.SPA.03.06.08E.pkg

cat3k_caa-wcm.SPA.10.2.180.0.pkg

packages.conf

[1]: No unnecessary package or provisioning files found. Nothing to clean

scg-keswick-ds-switch#copy usbf

scg-keswick-ds-switch#copy usbflash0:/ca

scg-keswick-ds-switch#copy usbflash0:/cat3k_caa-universalk9.

scg-keswick-ds-switch#copy usbflash0:/cat3k_caa-universalk9.16

scg-keswick-ds-switch#$sh0:/cat3k_caa-universalk9.16.03.05b.SPA.bin flash:/

Destination filename [cat3k_caa-universalk9.16.03.05b.SPA.bin]?

Copy in progress...CCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCC

539622403 bytes copied in 143.370 secs (3763845 bytes/sec)

scg-keswick-ds-switch#conf t

Enter configuration commands, one per line. End with CNTL/Z.

scg-keswick-ds-switc(config)#$generate rsa general-keys modulus 1024

% Please define a domain-name first.

scg-keswick-ds-switc(config)#ip domain-name abc.org.au

scg-keswick-ds-switc(config)#$generate rsa general-keys modulus 1024

The name for the keys will be: scg-keswick-ds-switch.abc.org.au

% The key modulus size is 1024 bits

% Generating 1024 bit RSA keys, keys will be non-exportable...

[OK] (elapsed time was 1 seconds)

scg-keswick-ds-switc(config)#exit

*Jul 29 18:47:47.398: %SYS-5-CONFIG_I: Configured from console by console ?

% Unrecognized command

scg-keswick-ds-switch#software install file flash:cat3k_caa-uni

scg-keswick-ds-switch#$ flash:cat3k_caa-universalk9.16.03.05b.SPA.bin ?

auto-rollback Auto-rollback time

force Proceed with installation without performing peer package

compatibility checks

new Create a new package provisioning file. After

installation, only packages contained in the installed

bundle will be part of the committed package set

on-reboot Suppress reload prompt and do not reload after

installation

provisioning-file Provisioning file to use for installation

switch Switch(es) where install operation is performed. Default

is all switches

verbose Verbose output

<cr>

scg-keswick-ds-switch#$3k_caa-universalk9.16.03.05b.SPA.bin verbose new force

Preparing install operation ...

[1]: Starting install operation

[1]: Expanding bundle flash:cat3k_caa-universalk9.16.03.05b.SPA.bin

*Jul 29 18:49:01.445: %IOSXE-7-PLATFORM: 1 process xlogger: [packtool]:(debug): command line: [-P 0 --operation expand --filename /flash/ca

*Jul 29 18:49:01.445: %IOSXE-7-PLATFORM: 1 process xlogger: t3k_caa-universalk9.16.03.05b.SPA.bin --destination /tmp/issu/provision/super_p

*Jul 29 18:49:01.445: %IOSXE-7-PLATFORM: 1 process xlogger: kgs -d]

*Jul 29 18:49:01.445: %IOSXE-7-PLATFORM: 1 process xlogger: file name = [/flash/cat3k_caa-universalk9.16.03.05b.SPA.bin]

*Jul 29 18:49:01.446: %IOSXE-7-PLATFORM: 1 process xlogger: package name = [INVALID]

*Jul 29 18:49:01.446: %IOSXE-7-PLATFORM: 1 process xlogger: pattern = [INVALID]

*Jul 29 18:49:01.446: %IOSXE-7-PLATFORM: 1 process xlogger: destination = [/tmp/issu/provision/super_pkgs]

*Jul 29 18:49:01.446: %IOSXE-7-PLATFORM: 1 process xlogger: operation = [expand]

*Jul 29 18:49:01.446: %IOSXE-7-PLATFORM: 1 process xlogger: debug = [4]

*Jul 29 18:49:01.446: %IOSXE-7-PLATFORM: 1 process xlogger: detail = [0]

*Jul 29 18:49:02.262: %IOSXE-7-PLATFORM: 1 process xlogger: Verifying parameters

*Jul 29 18:49:04.368: %IOSXE-7-PLATFORM: 1 process xlogger: ... parameters verified

*Jul 29 18:49:04.369: %IOSXE-7-PLATFORM: 1 process xlogger: Validating package type

*Jul 29 18:50:15.490: %IOSXE-7-PLATFORM: 1 process xlogger: bundle expanded

*Jul 29 18:50:15.500: %IOSXE-7-PLATFORM: 1 process xlogger: ... package type validated

*Jul 29 18:50:15.501: %IOSXE-7-PLATFORM: 1 process xlogger: Verifying package signatures

*Jul 29 18:50:16.238: %IOSXE-7-PLATFORM: 1 process xlogger: Signature verified on package cat3k_caa-guestshell.16.03.05b.SPA.pkg

*Jul 29 18:50:27.492: %IOSXE-7-PLATFORM: 1 process xlogger: Signature verified on package cat3k_caa-rpcore.16.03.05b.SPA.pkg

*Jul 29 18:50:28.083: %IOSXE-7-PLATFORM: 1 process xlogger: Signature verified on package cat3k_caa-webui.16.03.05b.SPA.pkg

*Jul 29 18:50:28.483: %IOSXE-7-PLATFORM: 1 process xlogger: Signature verified on package cat3k_caa-srdriver.16.03.05b.SPA.pkg [1]: Copying package files

*Jul 29 18:50:37.606: %IOSXE-7-PLATFORM: 1 process xlogger: Signature verified on package cat3k_caa-wcm.16.03.05b.SPA.pkg

*Jul 29 18:50:38.566: %IOSXE-7-PLATFORM: 1 process xlogger: Signature verified on package cat3k_caa-rpbase.16.03.05b.SPA.pkg

*Jul 29 18:50:38.567: %IOSXE-7-PLATFORM: 1 process xlogger: ... Package signatures verified

*Jul 29 18:50:38.567: %IOSXE-7-PLATFORM: 1 process xlogger: Copying package files [1]: Package files copied

*Jul 29 18:50:40.741: %IOSXE-7-PLATFORM: 1 process xlogger: cat3k_caa-guestshell.16.03.05b.SPA.pkg

*Jul 29 18:50:40.741: %IOSXE-7-PLATFORM: 1 process xlogger: cat3k_caa-rpbase.16.03.05b.SPA.pkg

*Jul 29 18:50:40.742: %IOSXE-7-PLATFORM: 1 process xlogger: cat3k_caa-rpcore.16.03.05b.SPA.pkg

*Jul 29 18:50:40.742: %IOSXE-7-PLATFORM: 1 process xlogger: cat3k_caa-srdriver.16.03.05b.SPA.pkg

*Jul 29 18:50:40.742: %IOSXE-7-PLATFORM: 1 process xlogger: cat3k_caa-wcm.16.03.05b.SPA.pkg

*Jul 29 18:50:40.743: %IOSXE-7-PLATFORM: 1 process xlogger: cat3k_caa-webui.16.03.05b.SPA.pkg

*Jul 29 18:50:40.743: %IOSXE-7-PLATFORM: 1 process xlogger: packages.conf

*Jul 29 18:50:40.863: %IOSXE-7-PLATFORM: 1 process xlogger: ... Package files copied

*Jul 29 18:50:42.876: %IOSXE-7-PLATFORM: 1 process xlogger: [packtool]:(debug): Ensuring that cached content is written to media [1]: Finished expanding bundle flash:cat3k_caa-universalk9.16.03.05b.SPA.bin

*Jul 29 18:50:46.314: %IOSXE-7-PLATFORM: 1 process xlogger: [packtool]:(debug): cached content flushed to media

*Jul 29 18:50:46.330: %IOSXE-7-PLATFORM: 1 process xlogger: SUCCESS: Finished expanding all-in-one software package.

*Jul 29 18:50:48.362: %IOSXE-7-PLATFORM: 1 process xlogger: [packtool]:(debug): Received script exit status 0 [1]: Verifying and copying expanded package files to flash:

[1]: Verified and copied expanded package files to flash:

[1]: Starting compatibility checks

[1]: Bypassing peer package compatibility checks due to 'force' command option

[1]: Finished compatibility checks

[1]: Starting application pre-installation processing

[1]: Finished application pre-installation processing

[1]: Old files list:

Removed cat3k_caa-base.SPA.03.06.08E.pkg

Removed cat3k_caa-drivers.SPA.03.06.08E.pkg

Removed cat3k_caa-infra.SPA.03.06.08E.pkg

Removed cat3k_caa-iosd-universalk9.SPA.152-2.E8.pkg

Removed cat3k_caa-platform.SPA.03.06.08E.pkg

Removed cat3k_caa-wcm.SPA.10.2.180.0.pkg

[1]: New files list:

Added cat3k_caa-guestshell.16.03.05b.SPA.pkg

Added cat3k_caa-rpbase.16.03.05b.SPA.pkg

Added cat3k_caa-rpcore.16.03.05b.SPA.pkg

Added cat3k_caa-srdriver.16.03.05b.SPA.pkg

Added cat3k_caa-wcm.16.03.05b.SPA.pkg

Added cat3k_caa-webui.16.03.05b.SPA.pkg

[1]: Creating pending provisioning file

[1]: Finished installing software. New software will load on reboot.

[1]: Committing provisioning file

[1]: Do you want to proceed with reload? [yes/no]: yes

System configuration has been modified. Save? [yes/no]: yes

Warning: Attempting to overwrite an NVRAM configuration previously written

by a different version of the system image.

Overwrite the previous NVRAM configuration?[confirm]

Building configuration...

Compressed configuration from 9619 bytes to 3259 bytes[OK]

[1]: Reloading

*Jul 29 18:55:57.091: %STACKMGR-1-RELOAD_REQUEST: 1 stack-mgr: Received reload request for all switches, reason User requested reload

*Jul 29 18:55:57.092: %STACKMGR-1-RELOAD: 1 stack-mgr: Reloading due to reason User requested reload

*Jul 29 18:55:57.592: %IOSXE-3-PLATFORM: 1 process sysmgr: Reset/Reload requested by [stack-manager].

scg-keswick-ds-switch#

<Sun Jul 29 18:55:57 2018> Message from sysmgr: Reason Code:[3] Reset Reason:Reset/Reload requested by [stack-manager]. [User requested reload]

umount: /proc/fs/nfsd: not mounted

Unmounting ng3k filesystems...

Unmounted /dev/sda3...

Warning! - some ng3k filesystems may not have unmounted cleanly...

Please stand by while rebooting the system...

Restarting system.

Booting...

Interface GE 0 link down***ERROR: PHY link is down

Getting rest of image

Reading full image into memory...Check base package header ...: done = 16384

Getting rest of image

Reading full image into memory....done

Reading full base package into memory...: done = 22301472

Bundle Image

--------------------------------------

Kernel Address : 0x53779384

Kernel Size : 0x34e9e1/3467745

Initramfs Address : 0x53ac7d65

Initramfs Size : 0x119d5bb/18470331

Compression Format: mzip

Bootable image at @ ram:0x53779384

Bootable image segment 0 address range [0x81100000, 0x81b8adc0] is in range [0x80180000, 0x90000000].

@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@boot_system: 623

Loading Linux kernel with entry point 0x816902d0 ...

Bootloader: Done loading app on core_mask: 0xf

### Launching Linux Kernel (flags = 0x5)

%IOSXEBOOT-4-FLASH: (rp/0): deleting cat3k_caa-universalk9.16.03.05b.SPA.bin because free space on flash is less than 300MB

%IOSXEBOOT-5c8e9d6656e9d89a8dedeae457871084-new_cksum: (rp/0): 4

%IOSXEBOOT-5c8e9d6656e9d89a8dedeae457871084-saved_cksum: (rp/0): 4

Front-end Microcode IMG MGR: found 4 microcode images for 1 device.

Image for front-end 0: /tmp/microcode_update/front_end/fe_type_6_0

Image for front-end 0: /tmp/microcode_update/front_end/fe_type_6_1

Image for front-end 0: /tmp/microcode_update/front_end/fe_type_6_2

Image for front-end 0: /tmp/microcode_update/front_end/fe_type_6_3

Front-end Microcode IMG MGR: Preparing to program device microcode...

Front-end Microcode IMG MGR: Preparing to program device[0]...594412 bytes.... Skipped[0].

Front-end Microcode IMG MGR: Preparing to program device[0]...393342 bytes.

Front-end Microcode IMG MGR: Programming device 0...rwRrrrrrrw..0%.........................................................................10%........................................................................20%..........................................................................30%........................................................................40%..........................................................................50%........................................................................60%.........................................................................70%..........................................................................80%........................................................................90%..........................................................................100%

Front-end Microcode IMG MGR: Preparing to program device[0]...25186 bytes.

Front-end Microcode IMG MGR: Programming device 0...rrrrrrw..0%....10%....20%......30%...40%......50%....60%......70%...80%......90%....100%wRr!

Front-end Microcode IMG MGR: Microcode programming complete for device 0.

Front-end Microcode IMG MGR: Preparing to program device[0]...86370 bytes.... Skipped[3].

Front-end Microcode IMG MGR: Microcode programming complete in 247 seconds

Both links down, not waiting for other switches

Switch number is 1

Restricted Rights Legend

Use, duplication, or disclosure by the Government is

subject to restrictions as set forth in subparagraph

(c) of the Commercial Computer Software - Restricted

Rights clause at FAR sec. 52.227-19 and subparagraph

(c) (1) (ii) of the Rights in Technical Data and Computer

Software clause at DFARS sec. 252.227-7013.

cisco Systems, Inc.

170 West Tasman Drive

San Jose, California 95134-1706

Cisco IOS Software [Denali], Catalyst L3 Switch Software (CAT3K_CAA-UNIVERSALK9-M), Version 16.3.5b, RELEASE SOFTWARE (fc1)

Technical Support: http://www.cisco.com/techsupport

Compiled Thu 02-Nov-17 11:07 by mcpre

licensed under the GNU General Public License ("GPL") Version 2.0. The

software code licensed under GPL Version 2.0 is free software that comes

with ABSOLUTELY NO WARRANTY. You can redistribute and/or modify such

GPL code under the terms of GPL Version 2.0. For more details, see the

documentation or "License Notice" file accompanying the IOS-XE software,

or the applicable URL provided on the flyer accompanying the IOS-XE

software.

% failed to initialize backup nvram

FIPS: Flash Key Check : Begin

FIPS: Flash Key Check : End, Not Found, FIPS Mode Not Enabled

This product contains cryptographic features and is subject to United

States and local country laws governing import, export, transfer and

use. Delivery of Cisco cryptographic products does not imply

third-party authority to import, export, distribute or use encryption.

Importers, exporters, distributors and users are responsible for

compliance with U.S. and local country laws. By using this product you

agree to comply with applicable laws and regulations. If you are unable

to comply with U.S. and local laws, return this product immediately.

A summary of U.S. laws governing Cisco cryptographic products may be found at:

http://www.cisco.com/wwl/export/crypto/tool/stqrg.html

If you require further assistance please contact us by sending email to

export@cisco.com.

cisco WS-C3850-48P (MIPS) processor (revision R0) with 865070K/6147K bytes of memory.

Processor board ID FOC1840U03B

2048K bytes of non-volatile configuration memory.

4194304K bytes of physical memory.

257008K bytes of Crash Files at crashinfo:.

1550272K bytes of Flash at flash:.

7815232K bytes of USB Flash at usbflash0:.

0K bytes of at webui:.

Base Ethernet MAC Address : 34:6f:90:f4:9f:80

Motherboard Assembly Number : 73-14442-10

Motherboard Serial Number : FOC1839662L

Model Revision Number : R0

Motherboard Revision Number : A0

Model Number : WS-C3850-48P

System Serial Number : FOC1840U03B

%INIT: waited 0 seconds for NVRAM to be available

WARNING: Command has been added to the configuration but Type 4 passwords have been deprecated.

Migrate to a supported password type

qos wireless-default-untrust

% Invalid input detected at '^' marker.

% switch-1:dbm:wireless:Channel 1 is already present in RRM active DCA list.

% switch-1:dbm:wireless:Channel 6 is already present in RRM active DCA list.

% switch-1:dbm:wireless:Channel 11 is already present in RRM active DCA list.

% switch-1:dbm:wireless:Channel 36 is already present in RRM active DCA list.

% switch-1:dbm:wireless:Channel 40 is already present in RRM active DCA list.

% switch-1:dbm:wireless:Channel 44 is already present in RRM active DCA list.

% switch-1:dbm:wireless:Channel 48 is already present in RRM active DCA list.

% switch-1:dbm:wireless:Channel 52 is already present in RRM active DCA list.

% switch-1:dbm:wireless:Channel 56 is already present in RRM active DCA list.

% switch-1:dbm:wireless:Channel 60 is already present in RRM active DCA list.

% switch-1:dbm:wireless:Channel 64 is already present in RRM active DCA list.

% switch-1:dbm:wireless:Channel 149 is already present in RRM active DCA list.

% switch-1:dbm:wireless:Channel 153 is already present in RRM active DCA list.

% switch-1:dbm:wireless:Channel 157 is already present in RRM active DCA list.

% switch-1:dbm:wireless:Channel 161 is already present in RRM active DCA list.

Press RETURN to get started!

*Jul 29 19:06:22.464: %SMART_LIC-6-AGENT_READY: Smart Agent for Licensing is initialized

*Jul 29 19:06:23.172: %PLATFORM-3-BACKUP_NVRAM_OPEN_FAIL: Failed to open backup nvram - No such file or directory.

*Jul 29 19:06:23.172: %IOSXE_RP_NV-3-BACKUP_NV_ACCESS_FAIL: Initial read of backup NVRAM contents failed

*Jul 29 19:06:23.623: %IOSD_INFRA-6-IFS_DEVICE_OIR: Device usbflash0 added

*Jul 29 19:06:27.457: dev_pluggable_optics_selftest attribute table internally inconsistent @ 0x125

*Jul 29 19:06:28.282: %SMI-5-CLIENT: Smart Install Client feature is enabled. It is recommended to disable the Smart Install feature when it is not actively used. To disable feature execute 'no vstack' in configuration mode

*Jul 29 19:06:28.445: %NBAR-6-CACHE_SYNC_INFO: Cache synchronization. Initialized.

*Jul 29 19:06:32.802: %SPANTREE-5-EXTENDED_SYSID: Extended SysId enabled for type vlan

*Jul 29 19:06:33.605: %LINK-3-UPDOWN: Interface Lsmpi18/0/3, changed state to up

*Jul 29 19:06:33.612: %LINK-3-UPDOWN: Interface EOBC18/0/1, changed state to up

*Jul 29 19:06:33.613: %LINK-3-UPDOWN: Interface GigabitEthernet0/0, changed state to down

*Jul 29 19:06:33.613: %LINK-3-UPDOWN: Interface LIIN18/0/2, changed state to up

*Jul 29 19:06:34.096: %PNP-6-PNP_DISCOVERY_STOPPED: PnP Discovery stopped (Startup Config Present)

*Jul 29 19:06:34.308: %HMANRP-6-HMAN_IOS_CHANNEL_INFO: HMAN-IOS channel event for switch 1: EMP_RELAY: Channel UP!

*Jul 29 19:06:05.464: %STACKMGR-1-STACK_LINK_CHANGE:Switch 1 R0/0: stack_mgr: Stack port 1 on switch 1 is nocable

*Jul 29 19:06:05.464: %STACKMGR-1-STACK_LINK_CHANGE:Switch 1 R0/0: stack_mgr: Stack port 2 on switch 1 is down

*Jul 29 19:06:05.464: %STACKMGR-1-STACK_LINK_CHANGE:Switch 1 R0/0: stack_mgr: Stack port 2 on switch 1 is nocable

*Jul 29 19:06:05.464: %STACKMGR-6-SWITCH_ADDED:Switch 1 R0/0: stack_mgr: Switch 1 has been added to the stack.

*Jul 29 19:06:34.799: %LINEPROTO-5-UPDOWN: Line protocol on Interface Lsmpi18/0/3, changed state to up

*Jul 29 19:06:34.799: %LINEPROTO-5-UPDOWN: Line protocol on Interface EOBC18/0/1, changed state to up

*Jul 29 19:06:34.800: %LINEPROTO-5-UPDOWN: Line protocol on Interface GigabitEthernet0/0, changed state to down

*Jul 29 19:06:34.801: %LINEPROTO-5-UPDOWN: Line protocol on Interface LIIN18/0/2, changed state to up

*Jul 29 19:06:37.413: %IOSXE_MGMTVRF-6-CREATE_SUCCESS_INFO: Management vrf Mgmt-vrf created with ID 1, ipv4 table-id 0x1, ipv6 table-id 0x1E000001

*Jul 29 19:06:40.580: %LINEPROTO-5-UPDOWN: Line protocol on Interface Vlan1, changed state to down

*Jul 29 19:06:46.198: %SYS-5-LOG_CONFIG_CHANGE: Buffer logging: level debugging, xml disabled, filtering disabled, size (51200)

*Jul 29 19:06:46.201: %AAAA-4-CLI_DEPRECATED: WARNING: Command has been added to the configuration but Type 4 passwords have been deprecated. Migrate to a supported password type

*Jul 29 19:06:46.213: %SYS-6-CLOCKUPDATE: System clock has been updated from 19:06:46 UTC Sun Jul 29 2018 to 04:36:46 ACST Mon Jul 30 2018, configured from console by vty0.

*Jul 29 19:06:46.215: %SYS-6-CLOCKUPDATE: System clock has been updated from 04:36:46 ACST Mon Jul 30 2018 to 04:36:46 ACST Mon Jul 30 2018, configured from console by vty0.

*Jul 29 19:06:47.443: %HMANRP-6-EMP_NO_ELECTION_INFO: Could not elect active EMP switch, setting emp active switch to 0: EMP_RELAY: Could not elect switch with mgmt port UP

*Jul 29 19:06:47.975: %LINEPROTO-5-UPDOWN: Line protocol on Interface Vlan103, changed state to down

*Jul 29 19:06:48.966: %LINK-5-CHANGED: Interface Vlan1, changed state to administratively down

*Jul 29 19:06:50.397: %SW_VLAN-6-VTP_DOMAIN_NAME_CHG: VTP domain name changed to SCGROUP.

*Jul 29 19:06:50.414: %SYS-5-CONFIG_I: Configured from memory by console

*Jul 29 19:06:52.778: %LINK-3-UPDOWN: Interface GigabitEthernet1/1/1, changed state to down

*Jul 29 19:06:52.780: %LINK-3-UPDOWN: Interface GigabitEthernet1/1/2, changed state to down

*Jul 29 19:06:52.783: %LINK-3-UPDOWN: Interface GigabitEthernet1/1/3, changed state to down

*Jul 29 19:06:52.784: %LINK-3-UPDOWN: Interface GigabitEthernet1/1/4, changed state to down

*Jul 29 19:06:52.785: %LINK-3-UPDOWN: Interface TenGigabitEthernet1/1/1, changed state to down

*Jul 29 19:06:52.786: %LINK-3-UPDOWN: Interface TenGigabitEthernet1/1/2, changed state to down

*Jul 29 19:06:52.788: %LINK-3-UPDOWN: Interface TenGigabitEthernet1/1/3, changed state to down

*Jul 29 19:06:52.789: %LINK-3-UPDOWN: Interface TenGigabitEthernet1/1/4, changed state to down

*Jul 29 19:06:53.778: %LINEPROTO-5-UPDOWN: Line protocol on Interface GigabitEthernet1/1/1, changed state to down

*Jul 29 19:06:53.779: %LINEPROTO-5-UPDOWN: Line protocol on Interface GigabitEthernet1/1/2, changed state to down

*Jul 29 19:06:53.783: %LINEPROTO-5-UPDOWN: Line protocol on Interface GigabitEthernet1/1/3, changed state to down

*Jul 29 19:06:53.784: %LINEPROTO-5-UPDOWN: Line protocol on Interface GigabitEthernet1/1/4, changed state to down

*Jul 29 19:06:53.785: %LINEPROTO-5-UPDOWN: Line protocol on Interface TenGigabitEthernet1/1/1, changed state to down

*Jul 29 19:06:53.786: %LINEPROTO-5-UPDOWN: Line protocol on Interface TenGigabitEthernet1/1/2, changed state to down

*Jul 29 19:06:53.787: %LINEPROTO-5-UPDOWN: Line protocol on Interface TenGigabitEthernet1/1/3, changed state to down

*Jul 29 19:06:53.789: %LINEPROTO-5-UPDOWN: Line protocol on Interface TenGigabitEthernet1/1/4, changed state to down

*Jul 29 19:06:56.168: %SYS-5-RESTART: System restarted --

Cisco IOS Software [Denali], Catalyst L3 Switch Software (CAT3K_CAA-UNIVERSALK9-M), Version 16.3.5b, RELEASE SOFTWARE (fc1)

Technical Support: http://www.cisco.com/techsupport

Compiled Thu 02-Nov-17 11:07 by mcpre

*Jul 29 19:06:56.539: %SSH-5-ENABLED: SSH 2.0 has been enabled

scg-keswick-ds-switch>

scg-keswick-ds-switch>en

scg-keswick-ds-switch#

scg-keswick-ds-switch#show version

Cisco IOS Software [Denali], Catalyst L3 Switch Software (CAT3K_CAA-UNIVERSALK9-M), Version 16.3.5b, RELEASE SOFTWARE (fc1)

Technical Support: http://www.cisco.com/techsupport

Compiled Thu 02-Nov-17 11:07 by mcpre

licensed under the GNU General Public License ("GPL") Version 2.0. The

software code licensed under GPL Version 2.0 is free software that comes

with ABSOLUTELY NO WARRANTY. You can redistribute and/or modify such

GPL code under the terms of GPL Version 2.0. For more details, see the

documentation or "License Notice" file accompanying the IOS-XE software,

or the applicable URL provided on the flyer accompanying the IOS-XE

software.

ROM: IOS-XE ROMMON

BOOTLDR: CAT3K_CAA Boot Loader (CAT3K_CAA-HBOOT-M) Version 4.68, RELEASE SOFTWARE (P)

scg-keswick-ds-switch uptime is 1 minute

Uptime for this control processor is 9 minutes

System returned to ROM by Power Failure at 03:58:14 CDT Fri Mar 17 2017

System image file is "flash:packages.conf"

Last reload reason: Power Failure
